Position:Home > Products > Powder Mill > Micro Powder Mill

Powder Mill

Micro Powder Mill

micro powder mill



Micro Powder Mill has been widely used in making fine powder or micro powder, CLIRIK Micro Powder Mill is applicable to non-flammable and non-explosive materials with hardness less than 6, such as the calcite, chalk, limestone, dolomite, kaolin, bentonite, talcum, talc, magnesite, illite, pyrophyllite, vermiculite, sattapulgite, rectorate, diatomite, barite, gypsum, alum earth, graphite, fluorite, variscite, potash ore floatstone,etc.

As one of the best Micro Powder Mill manufacturers, CLIRIK has developped and manufactured more and more advanced grinding machine. The super-micro grinding mill is kind of popular micro milling machine. The ultrafine mill is invented by absorbing advantages from the same trade home and abroad.

Working principle of Micro Powder Mill:


After crushed by hammer crusher, the large materials are crushed into small ones and sent to storage hopper by elevator, and then evenly sent to the upper distribution plate of the turnplate by vibrating feeder and sloping feeding pipe.

When the micro powder mill is at work, all the grinding rollers are rolling in the ring, and the materials are driven to the edge of the turnplate by the centrifugal force and fall down into the grinding chambers where the materials are repeatedly pressed, crushed and grinded by the rollers.

The high-pressure air blower constantly inhales air within the micro powder mill and, in turn, the airflow with crushed materials are brought to the classifier whose high-speed impeller will screen the airflow: the unqualified particle size will fall and return to the mill for being reground while the qualified particle size mixed with air will go into the cyclone powder collector. Most of the qualified powders will fall and exit from the discharging valve at the bottom; a small proportion of the fine powders, with airflow, moves to the dust cleaner, and clings to the surface of the filter bags. At the same time, the fine powders clinging to the surface fall down by the sudden vibration of the filter bags, which is caused by the instantly ejected high-pressure gas controlled by the pulse valve. The materials from the above two lots are sent by the conveyor at the bottom to get finished powders packed. In addition, filtered clean air will be emitted from the air outlet of muffler in the end.

Micro powder mill Features:

This Micro powder mill is of lots features and benefits, such as the high efficiency in same condition of finished particle size and power of motor. The output of the micro milling machine is 40% higher than airflow mill and whisk mill. In same condition of material and finished particle size, the quick-wear part of the Micro powder mill is of high using rate and longer lifetime than traditional milling machine. Because there are no axle tree and bolt in the grinding an trum, there will be no wear out of bearing and sealing part and also no loose of bolts which will greatly improve the safety of the Micro powder mill. What's more, the Micro powder mill will greatly lighten polution and noise by using dust cleaner and muffler, which has achieved environmental protection requirement.

For more info about this Micro powder mill, you can contact us. CLIRIK will provide you with best micro milling machine and perfect service.
